Compact Multi-Gas Warning & Measuring Instrument (Ex)
Sewerin’s EX-TEC PM 5xx and EX-TEC PM 400 are rugged, explosion-proof mobile gas detectors engineered to protect utility and industrial professionals from hidden atmospheric hazards. The EX-TEC PM 5xx series serves as an all-in-one multi-gas powerhouse, capable of simultaneously monitoring up to five gases to pinpoint leaks and assess explosion risks with absolute precision. It features intuitive one-handed operation and a razor-sharp, sunlight-readable display to ensure maximum efficiency during demanding field operations.
Meanwhile, the highly adaptable EX-TEC PM 400 is a compact warning device that detects up to four toxic or flammable gases, delivering instant visual and acoustic alarms the second danger arises. Elevate your worksite safety and experience the life-saving capabilities of these advanced instruments by requesting a live product demo today.
| Models | PM 400 (050 01), PM 400 CO2 (050 02), PM 500 (050 11), PM 550 (050 21), PM 580 (050 31) |
|---|---|
| Certificate | TUV 17 ATEX 171969 X; IECEx TUN 17.0027 X; CSA19CA80006793X |
| Marking | Ex ia db IIC T3 Gb (PM 400: Ex ia da IIC T3 Ga); I.S. Class I Div 2 (PM 400: Div 1) |
| Dimensions (W x D x H) | 93 x 47 x 165 mm (65 mm deep with belt clip) |
|---|---|
| Weight | approx. 500 g (523 g with belt clip) |
| Material | Polycarbonate / thermoplastic polyurethane housing |
| Display | 380 x 224 colour TFT, 56 x 33 mm |
| Operation | Membrane keypad |
| Memory | 8 MB |
| Interface | USB 2.0 (PM 5 / PM 5-T docking station) |
| Gas connection | Rectus NW 2.7 quick-release coupling |
| Protection rating | IP65 |
| Infrared (flammable) | CH4, C3H8 (PM 580/550/500) |
|---|---|
| Semiconductor (SC) | Flammable gases (PM 580 plus) |
| Catalytic combustion (CC) | CH4, C3H8, C9H20, C2H2, H2, jet fuel (PM 400) |
| Infrared CO2 | Optional |
| Electrochemical (EC) | O2, CO, H2S (by model) |
| Pump | Diaphragm, >150 mbar, >10 l/h, F100 <= 5 l/h |
|---|---|
| Operating temperature | -20 to 40 C |
| Humidity | 5-95 % r.h., non-condensing |
| Atmospheric pressure | 700-1200 hPa |
| Battery | PM 5 battery pack (NiMH 3 x 1.2 V) |
|---|---|
| Operating time | Up to 16 h (warning application) |
| Charging time | approx. 5 h |
| PM 580 - detection, warning & measurement | Methane, Propane, Hydrogen Sulfide, Carbon Monoxide, Oxygen, Carbon Dioxide |
|---|---|
| PM 550 - detection & measurement | Methane, Propane, Hydrogen Sulfide, Carbon Monoxide, Oxygen, Carbon Dioxide |
| PM 500 - warning only | Methane, Propane, Hydrogen Sulfide, Carbon Monoxide, Oxygen, Carbon Dioxide |
| PM 400 - warning only | Methane, Propane, Nonane, Acetylene, Jet Fuel, Hydrogen, Carbon Monoxide, Oxygen, Carbon Dioxide |
